📈 How to Calculate a Custom Drag Model (CDR)
- Projectiles
- 3 Replies
Does the software let you begin with a standard drag model? If so you can compare your velocity to the calculated velocity, and where your data is different, begin increasing or decreasing drag coefficient at that velocity.
For the very blunt projectiles mentioned try using the wadcutter reference drag law as the starting point. You will then have to model each short distance between measured velocities one at a time, adjusting the drag law up or down to get a match. Start with the highest velocities. Once you have the first pair of velocities matched, move on to the second pair and repeat, but do not change the drag coefficient you got for the first pair. Do this along your trajectory until you have drag coefficient values for each part of the trajectory. It is quite likely that you will end up with values varying wildly from one speed to the next, so what you will have to do then is plot all the values you have calculated and put a best fit line through the data by eye, do not try to use a curve fitting routine from the spreadsheet.
When you have finished, try out your result and tweak to get the closest you can to the measured velocities. Hopefully this will get you somewhere close to what you want, but it may need a bit more work.
If you need more help, PM me.
Good luck.
THANK YOU, David and Miles, thanks a lot!!
Yes, this looks like a doable plan.
I already imported the WC₀ drag model into Strelok Pro.
Matthias
