Air Venturi Avenge-X PCP Tuning Guide, AEAC Pre-video Learning
- Thread starter Airgun Nation
- Start date
https://penchetta.com/huggett-snipe-standard-ldc-moderator-25/ this the same one i assume will be ordering it next week or soI bought my Huggets snipe moderators from this website, they come in the same size of your airguns caliber not like the DonnyFL that they recommend one size up. The new Yokozuna weight twice more than the Hugget that’s why I discarded them. Good luck
Penchetta Fine Writing, Amazing Knives and Wet Shaving
The #1 place in Arizona to source fine writing instrutments, quality stationary, high end and custom knives and wet shaving supplies.penchetta.com
Upvote 0
Here is how my avenge-x .22 was shooting with the sumo
Here is how it was shooting without the sumo
I completely took apart the Sumo, cleaned and inspected it. It needed cleaning. Found a very minor clip on the exit ring and filed it. Major difference when reinstalled. Shooting way better. Shot today with and without the Sumo. Approx 3100psi start, reg at 2000 and Hammer 1.5 turns in. Velocity was around 890fps average. Best group with the Sumo was 8.23mm, worst was 35mm. With the Sumo removed, best group was 7mm, worst was 15mm. 45 shots each time. Looks like I need a new moderator. Here is the paper: Left side with the Sumo 199 to 207, Right side without, 208 to 212+ a few not numbered. Definitely better without the moderator. Now to choose a moderator.
I completely took apart the Sumo, cleaned and inspected it. It needed cleaning. Found a very minor clip on the exit ring and filed it. Major difference when reinstalled. Shooting way better. Shot today with and without the Sumo. Approx 3100psi start, reg at 2000 and Hammer 1.5 turns in. Velocity was around 890fps average. Best group with the Sumo was 8.23mm, worst was 35mm. With the Sumo removed, best group was 7mm, worst was 15mm. 45 shots each time. Looks like I need a new moderator. Here is the paper: Left side with the Sumo 199 to 207, Right side without, 208 to 212+ a few not numbered. Definitely better without the moderator. Now to choose a moderator.
Upvote 0
Ordered a Snipe from Penchetta Pen & Knife. Better priced than anyone else on the Web that I saw.Thanks RayPR.
Upvote 0
Just wanted to update this!. Parts are indeed on pyramid the lady at air venturi told me there working on the catalog pictures for the parts along with the tactical schematic will be posted very soon got my rifle back together I am happy camper !. Note the part I broke was only $5.99 another thing any tactical owners MAKE sure right after shooting to put the ar style stock back to the closed position just to avoid knocking the rifle over. when fully extended it seems to have a weak Point I guess to much leverage on the plastic mount or during travel if you use a soft case !. Mine was knocked off a plastic table onto grass and the Pic I posted is what took place!. Maybe all of like 2 ft tall table if that!.
Upvote 0
Using the stock Avenge-X Shroud adapter which the Avenger does not have. I use the Donny Fl Adapter on my Avenger. Good Question. I bought a Hugget Snipe which I haven't tried yet. I'm worried that it is rated .177 - .22 cal, maybe pellet clipping again? I just dry fired both the Sumo and Snipe for a sound test, probably 30 rounds each. I can't tell the difference in sound level between the two. Both make a huge difference from no suppressor. Very Quiet Will try the Snipe today even though it's only about 15 deg out. Cold for Seattle.
Upvote 0
My orings on my reg failed and I degassed and unscrewed and the one on the tip was like hard plastic as well! It just snapped into pieces like hard plastic when I tried to remove. No wonder the reg quit working. Does anybody on the forums know the exact oring size for the regulator tip that goes into gun? I know their 90 durometer but would like to find some of these on Amazon on the cheap. Thanks for listening!
Upvote 0
The O rings that came with the Avenge X should be in the box. Use your calibers to measure to identify.
Upvote 0
Thanks for the great video guide on the rifle, recently bought my first avenge x .22 so this helped plenty to get some background in the tuning/setup side of things. I am shooting 18.13 gr pellets at the moment. To get the gun below 900fps I dropped the reg to 1500psi and my hammer spring is completely backed out, average fps now is 880.
Not sure if it is because I am at 5751feet above sea level that I can go so low on the reg. Will still play to push speed up a little and still need to see total shot count with reg set @ 100bar. My bottle version is only 250bar not 300 but have yet to test total shot count at this setting
Not sure if it is because I am at 5751feet above sea level that I can go so low on the reg. Will still play to push speed up a little and still need to see total shot count with reg set @ 100bar. My bottle version is only 250bar not 300 but have yet to test total shot count at this setting
Upvote 0
keep em rolling
I had the exact issue with my tactical version. I replaced the OEM chassis with the Saber Tactical. I would sight it in, go hunting, and the next day the POI would change and was having the same 1 in 5 flyers. I took the barrel off, cleaned it and torqued the two screws that hold the barrel in place. Fixed the problem for a couple of days.
I ordered the Evolve 3D barrel band. I reset the barrel the installed the barrel band. It’s been 3 months and over 1000 shots and not one problem with POI shift . Plus The groups past 50 yards shrunk considerably. The Evolve 3D barrel band secures the barrel much more securely and keeps it from getting knocked around while beating the gun around in the woods.
Last edited:
Upvote 0
sadly they no longer sell them :-(I bought my Huggets snipe moderators from this website, they come in the same size of your airguns caliber not like the DonnyFL that they recommend one size up. The new Yokozuna weight twice more than the Hugget that’s why I discarded them. Good luck
Penchetta Fine Writing, Amazing Knives and Wet Shaving
The #1 place in Arizona to source fine writing instrutments, quality stationary, high end and custom knives and wet shaving supplies.
Upvote 0
Have anybody found any aftermarket heavier hammer made for the Avenge-X? There's spring upgrade available on ebay but haven't seen any heavier hammer available.
Upvote 0
In trying to help u, since I am very familiar with the product, I suggest that you consider that a change of hammer weight would not be advantageous. It has a large range of tuning ability. For more info, you can call Air Venturi +1 (216) 292-2570, usually Stacey or Ted should help. Where did you buy it and when?
Upvote 0
