Tune a Beeman R7?

Jump to latest Follow Reply
readyfisher9

readyfisher9

Member
Apr 10, 2017
330
259
76
. Bakersfiel California, United States
I bought a Beeman R7 recently, and have been breaking it in. The JSB Exact RS Diabolo 7.33 grain pellet does the best, but others work out well. Question: Is it worth the money and effort to replace the original spring, or go with a tune using the Vortek Pro-Guide 4 Tuning Kit? And is that the best, or maybe the ARH Maccari kit? I am going for max smooth, not a harder-hitting gun.

  • Like
Reactions: Greenarrow, beerthief and TXRMike
Congrats, the .177 R7/hw30 is as close to a "must have" spring gun as you can get.

I've used both Vortek and ARH kits in mine and had good outcomes with both. But IMHO, the ARH kits are less snappy and deliver a more mellow (some would say smoother) shot cycle with a bit less power.

A tune kit with spring, guide, seal and moly will likely run upwards of $95-$100. That is likely more than 25% of the price of the gun. The improvement is noticeable, but I think also often exaggerated. Worth it? Yes in my view, but probably not for the occasional shooter.

R

  • Like
Reactions: Greenarrow
Upvote 0
I shot mine fro 5,000 or so. Then it started to sound crunchy when cocking. I installed a Vortek kit, but did not take the piston out. I have another 5,000 through it since then and all is good, still running the factory seal.

The original spring took a set and was curved like a banana. The kit made a world of difference, much nicer shot cycle than when new.

The power did not change at all, shooting 7.33 @680fps and 7.0 wadcutters @700 or so.

  • Like
Reactions: BABz58 and TXRMike
Upvote 0
I had ten of thousands of shots in my R-7 before I tuned it,first used the ARH kit, really liked it , then put the Vortek kit in it,it changed to shooting cycle;just as
Emrider says,I like the ARH kit better,but the Vortek is also good.....I will say ARK ALL THE WAY!
Question was,"is it worth it"? , wait until you have thousands of pellets through it=think $100 and time,is it worth it to you,your R-7 will benefit from a tune job for sure,but it can wait

Upvote 0
Struckat said:
The power did not change at all, shooting 7.33 @680fps and 7.0 wadcutters @700 or so.
Click to expand...
That's right where my new R7 is and it shoots pretty smooth for right out of the box ! The
Air Arms Falcons 7.33 gr are accurate and give slightly better velocity than the
JSB's. My last test with the AA was 688 fps.

  • Like
Reactions: Struckat and Teber66
Upvote 0
I do like the job st take it apart lol ke your going to do a tune and just clean up the factory lube job and go back with a fresh relube . Insure its lubed well in the spring tube.. may not even need tar stuff just a proper moly grease .. you maybe surprised just how much ywang and all that could do . Your going to need a jar of moly anyway add to a kit.

Upvote 0
I have decided just remain stock until I shoot it more. At 25 yards, a perfect hole dead center is very possible if I do my part. My HW97K has only a slight edge if any. Stuckat is right IMO, the AA Falcons 7.33 are amazing. First rifle or last, every spring gunner should have a Beeman R7.


  • Like
Reactions: maxtrouble, JohnTaylor, TXRMike and 5 others
Upvote 0
Hi , i’m thinking of purchasing the same gun but have some hesitation.
Does your gun have any gaulling or rubbing issues from the two piece cocking leaver? I recently purchase a new WH 50s and the cocking arm was grinding against the bottom of the receiver and also had extensive barrel droop. Darn! Quite disappointing. I probably should’ve sent it back but decited to deal with it as the gun seemed to be very accurate. It was also extremely twangy so I installed a PG 4 Vortek kit . I am very pleased with the improvement. I have managed to eliminate the gaulling but cocking is still pretty crunchy. I also fixed the droop by putting some Hawke droop compensation ring inserts in my two piece scope mounts. I also jam my ear plugs in deeper so I don hear the crunching as this doesn’t appear to affect the guns accuracy. Thanks ,
Al

Last edited:
  • Like
Reactions: Paul Be Careful and BABz58
Upvote 0
I have a relatively ancient, original Beeman "Goudy" stocked R7 from the 90's. Stuck in an ARH spring and lubes years ago, running the OEM piston seal. It's a fabulous combo, though I agree on a new gun there's probably no quantum leap to be had. I have yet to try a Vortek kit.

And I've never had a gun more startlingly transformed by ammo choice! Nice enuff with many pellets, but a near-recoilless laser with the Air Arms Falcon. Dead accurate, dead smooth, and faster than anything else I've tried - even the 7-grain RWS Hobby.

Last edited:
  • Like
Reactions: fishing43
Upvote 0
fullpower said:
Hi , i’m thinking of purchasing the same gun but have some hesitation.
Does your gun have any gaulling or rubbing issues from the two piece cocking leaver? I recently purchase a new WH 50s and the cocking arm was grinding against the bottom of the receiver and also had extensive barrel droop. Darn! Quite disappointing. I probably should’ve sent it back but decited to deal with it as the gun seemed to be very accurate. It was also extremely twangy so I installed a PG 4 Vortek kit . I am very pleased with the improvement. I have managed to eliminate the gaulling but cocking is still pretty crunchy. I also fixed the droop by putting some Hawke droop compensation ring inserts in my two piece scope mounts. I also jam my ear plugs in deeper so I don hear the crunching as this doesn’t appear to affect the guns accuracy. Thanks ,
Al
Click to expand...
Unless you specifically want a lighter, smaller, short-range plinker, there’s really no need to get an HW30 if you already own an HW50.
