Umarex Notos Folding Stock

Jump to latest Follow Reply
EmptyTin_Tim said:
Yooooo I emailed Buck Rail a bit ago and now on his site he says he will be doing side folders with mil spec tubes and also you can get a different grip!!! (Scroll down)

buck-rail.com

New Products and New Projects!

Just a quick update. I’ve just listed a couple of new products and have some project updates. Let me tell you about it. Black Arts Design We’re now offering Air Venturi Avenger Barrel b…
buck-rail.com buck-rail.com
Click to expand...
I don't really like how the stock/tube is not in line with the rail/shroud. Wish it was more in line instead of a drop

Upvote 1
frankenvenger said:
I don't really like how the stock/tube is not in line with the rail/shroud. Wish it was more in line instead of a drop
Click to expand...
That was something I noticed too. I'm thinking it is similar to the Avenger tac stock he makes where he did that on purpose to get access to the hammer spring while the stock is on? Hard to tell with just the one photo.

Other thing I can't tell is if the stock folds left or right. In my email I said he should make it fold right since the cocking lever is on the left so you could actually use the gun when it's folded.

  • Like
Reactions: OnTargetAirgunner
Upvote 0
buck-rail.com

Umarex Notos AR Conversion Kit

Umarex Notos AR Conversion Kit All parts Made in USA, in-house, by a veteran-owned business LIFETIME WARRANTY on the Nylon Grip and Handguard Add an AR adjustable stock & grip to the Notos &amp…
buck-rail.com buck-rail.com

buck-rail.com

UTG Side Folding Stock Adapter

UTG Side Folding Stock Adapter UTG Brand. Sold and Shipped by Buck Rail Aerospace grade aluminum. Matte Black Anodized finish. Designed to fold to the left but can be made to fold right as well. Lo…
buck-rail.com buck-rail.com

Okay guys here we go, will see how well this works!

  • Like
Reactions: OnTargetAirgunner
Upvote 0
OnTargetAirgunner said:
I don't really like how the stock/tube is not in line with the rail/shroud. Wish it was more in line instead of a drop
Click to expand...
I'm new to the game and I have a NOTOS.Did anyone find the right parts to make to stock fold. ? They have them on Bucks site,but have been out of stock for awhile. They have all the other parts,just not the part that makes it fold......thanks Gary

  • Like
Reactions: Airgun Al
Upvote 0
GARY HASTINGS said:
I'm new to the game and I have a NOTOS.Did anyone find the right parts to make to stock fold. ? They have them on Bucks site,but have been out of stock for awhile. They have all the other parts,just not the part that makes it fold......thanks Gary
Click to expand...
Yeah I got that part buck sells it works well the problem is he said in a newsletter that the company that makes it is going to stop so that's probably why not in stock now.

Upvote 0
So does anyone have a Notos side folding adapter that they want to part with. I really want to tu my notos into a backp gun. I also am wondering how much barrel is underneath the stock shroud. Can I remove the shroud and just attach a moderator to the end off the barrel, just like I did to my hatsan vectors. That was way too simpl, a few screws and the factory shroud slipped off and then a hacksaw, and a 14mm deep socket to take off some sort of end of the barrel nut and then I had a vectis under 35 inches long. Made it a really good brush gun. I just wish it was.30 or bigger. Than it would be a really good deer gun in the Texas woods. Anyone want to sell or horse trade. Let me know

Upvote 0
The Notos barrel is 12-1/2+" long, it's overmolded with fiber reinforced thermoplastic and is retained with 2 imbeded c-clips and a sizeable depression to hold it securely to the barrel.

To remove the moderator housing from the barrel cleanly, you need access to a lathe and then part the overmold at 5-1/2" from the face of the moderator housing.

I trim the crown off and reset it to 11° just because I have the tool to do so. Then I thread the barrel end to 1/2 x 20 UNF and then face the removed moderator housing and tap it with 1/2 x 20 UNF threads.

  • Like
Reactions: mandn
Upvote 0
someone needs a folding stock adapter ?? I got 5 of them that I can let then go


  • Like
Reactions: Chief Ten-Beers and Airgun Al
Upvote 0
bigmike said:
Hello Notos owners.
I am wondering if the stock tube threads are standard AR-15 threads. Thinking of buying one but am wondering if I would be able to install a folding stock adapter like one from SB Tactical.

Thanks
Click to expand...
try buck-rail.com they got all the parts that you may need for your notos except the folding adapter but luckily for you I got a few that I can let them go just let me know

Upvote 0
hunt4atomo said:
yes I'm gonna send it to you I just need a week because I'm away from home right now but no worries you going to get it for free just send me a address where you wanna to
Click to expand...
Thanks for the very generous offer!
I sent you a message with my shipping details.
And if you would include a invoice to let me know what I owe you, Id be more than happy to pay you!
Thanks much!

Upvote 0
