Tuning Wildcat MKI ST barrel need help getting shroud off

[pesty3782]

I pulled the barrel on a used wildcat MKI in 177 yesterday to clean the barrel because for the life of me i can't get 13's or 10.34 to shoot at all. I understand the shroud should just unscrew but no go at all.....I can even place the shroud in a vice with rubber pads and use a set of vice grips with leather on the barrel and I can't get this shourd to come apart. Any ideas?

Tony P.



[nervoustrig]

Apply some heat from a heat gun or a propane torch to soften the threadlocker. Unscrew it while hot.



[pesty3782]

Thanks....I will give that a try today.

Tony P.



[Revoman]

Actually, I believe that there is a 'hidden' set screw within a bushing that holds the shroud on a Gen I Wildcat. It's been quite a while since I had mine, but that's what I remember. You may wanna check on YouTube before going too far as you will ruin the shroud if not done properly.

mike



[pesty3782]

Barrel is apart and thanks for all the advice!!!!! I learned the set screw is attached to the rear section of threads that the shroud screws into. It took heat to remove the front section so I could get the shroud off. I had used a pull through cleaner on this barrel before, but here is what came out the first push of a 177 brass brush....that is a 177 patch with "chunks" of lead on it. I cleaned, polished the barrel and now will get it back together to see if I can get any groupings from this barrel which so far I have not been able to obtain.

Thanks for all the help

Tony P.

.



[Bigragu]

Barrel is apart and thanks for all the advice!!!!! I learned the set screw is attached to the rear section of threads that the shroud screws into. It took heat to remove the front section so I could get the shroud off. I had used a pull through cleaner on this barrel before, but here is what came out the first push of a 177 brass brush....that is a 177 patch with "chunks" of lead on it. I cleaned, polished the barrel and now will get it back together to see if I can get any groupings from this barrel which so far I have not been able to obtain.

Thanks for all the help

Tony P.

.

This is the reason I only use pull thru’s in remote areas for an emergency quick clean only, and it is not my preferred way to clean a barrel.

if an airgun’s barrel is removable it always goes on a padded vice for a good hour session with the Dewey rod, brass brush, and mops. To me, it is the correct and best method to 100% clean a barrel. Pull thru’s are short cut methods, have their place, but are not the best way



[Strobing_NYC]

I also have a MK1 Wildcat in .22 and it's one of my best beater truck guns I have. You'll need to use a heatgun or torch the first time for most parts but once everything is broken free your golden. Open up your transfer port and pellet probe grab a HUMA reg and set @ 135 and enjoy! I even get OK groups with Slugs with the ole ST barrel lol, mostly shoot H&N Barracuda's gun loves them...



[pesty3782]

Thanks I have a Huma in it and it is set right now at 120...Hope to get it out today and see how it groups.

Tony P.



[elh0102]

if an airgun’s barrel is removable it always goes on a padded vice for a good hour session with the Dewey rod, brass brush, and mops. To me, it is the correct and best method to 100% clean a barrel. Pull thru’s are short cut methods, have their place, but are not the best way

This is the reason I only use pull thru’s in remote areas for an emergency quick clean only, and it is not my preferred way to clean a barrel.

It is the best way if it NEEDS it. A good barrel with no machining anomalies, shooting at standard velocities, should rarely, if ever need scrubbing with a rod and brush. I currently have 6 PCP rifles, and only one ever needs to be cleaned with a brush. And yes, it you are getting visible chunks of lead on your patch, then something needs further investigation. Maybe I've been lucky, but this has been my experience.



[Strobing_NYC]

The biggest thing with the MKI is pellet probe aliment with the port on the block. You do this by loosening the 4 screws on the airtube and sliding the whole action back and forth.

You can drill some 1-2mm holes in the Shroud to help with sound levels. I have 5-2mm holes in mine with sponge material inside to help with damping and sound reduction.

I believe Ernest has a video on this on the Tube. Man I can not tell you how much I have enjoyed this pellet pusher, super quite and super fun. Just wish it had a bigger mag capacity and larger air tank or a way to put a bottle on. I'm sure I could probably Mcgiver a bottle on but not worth the time and energy

Enjoy your Wildcat if you have any questions Email me directly [email protected]



[pesty3782]

I did forget about the aliment and will find the video and watch it to see what I need to do.

Thanks!

Tony P.



[Revoman]

Once you align it properly, and are certain, mark the bands holding it on in case you need to remove them later.

mike



[pesty3782]

Well I took the whole rifle apart and I am glad I did. There was varnish all over the hammer and crap all though the trigger parts. I followed the video Ernest has up and aligned the probe to the specs he said. Tomorrow I hope to get it on a chrono and see if I get a consistent spread.

Tony P.
